Name: Customized LOGO Printing 52mm Diameter Empty Spray Aerosol Tin Can
Availability: InStock

Customized LOGO Printing 52mm Diameter Empty Spray Aerosol Tin Can

The 52mm aerosol can is a vital solution for industrial and domestic cleaning applications, particularly when using clean solvents. Its compact and lightweight design ensures exceptional portability, enabling effortless handling and efficient storage.

Item No :
52mm Empty aerosol tin can
Order(MOQ) :
9000
Payment :
30% deposit, 70% balance before loading the container.
Product Origin :
Guangzhou China
Color :
CMYK printing
Shipping Port :
Guangzhou/Shenzhen
Lead Time :
20-25 days

Inquire Now

Product Details

The empty aerosol can for Chemical spray, customize your metal packaging size and design according to the purpose of the product. Accept custom color with CMYK printing or pantone color printing

Specification Data For Different Diameter

NO.	Descreiption	Dia 45(mm)	Dia 52 (mm)	Dia 57 (mm)	Dia 65 (mm)
A	I/S CUP OPENING	25.4 ± 0.1	25.4 ± 0.1	25.4 ± 0.1	25.4 ± 0.1
B	O/S CUP OPENING	31.2 ± 0.2	31.2 ± 0.2	31.2 ± 0.2	31.20 ± 0.2
C	TOP OF CURL TO THE TOP OF THE TOP DOUBLE SEAM	5.2 ± 0.25	8.5±0.25	9.3 ± 0.25	13.2 ± 0.25
J	CONTACT HEIGHT	4 ± 0.15	4 ± 0.15	4 ± 0.15	4 ± 0.15
K	TOP DOUBLE SEAM OUTSIDE DIAMETER	43.8 ± 0.15	50.9+0.1 /-0.15	55.8 ± 0.15	63.25 ± 0.15
S	VERTICAL DISTANCE, TANGENT TO THE OUTSIDE DIAMETER OF THE DOME DOUBLE SEAM – TOP OF THE DOME DOUBLE TO THE NECKED-IN AREA OF THE CAN SIDEWALL	6.7± 0.2	6.7±0.2	6.7 ± 0.2	6.9 ± 0.2
T	WIDTH OR HEIGHT OF TOP DOUBLE SEAM	3± 0.2	3.1±0.2	3 ± 0.2	3.2 ± 0.2
V	BODY OUTSIDE DIAMETER	45.2 ± 0.2	52.5 ± 0.2	57 ± 0.2	65.5 ± 0.2
D	TOP OF THE TOP DOUBLE SEAM TO THE BOTTOM OF THE BOTTOM DOULBE SEAM	D±0.5	D±0.5	D±0.5	D ± 0.5
E	OVERALL HEIGHT	(D+5.5)±1.0	(D+8.8)±1.0	(D+9.6)±1.0	(D+13.5) ±1.0
